BMW 3 Series Sedan (G20), technical data

THE 3

THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 3 Series Sedan.

Read more
THE 3THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA
    BMW 3 Series Sedan: Overview

    TECHNICAL DATA OF THE BMW 3 SERIES SEDAN.

    Select model

    Weight

    Unladen weight EU in kg 1,545 [1,565]
    Max. permissible weight in kg 2,050 [2,050]
    Permitted load in kg 580 [560]
    Permitted axle load front/rear in kg 965/1,160 [965/1,150]
    Luggage capacity min. (seats up or roof down) in l 480
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,300
    Trailer load 12% (braked) in kg 1,300

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 115 (156)/4,500-6,500
    Engine torque (Nm) at 1/min 250/1,300-4,300
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 225 [223]
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 8.9 [8.4]

    Fuel consumption

    Combined in l/100 km 7.2-6.3
    CO2 combined emissions in g/km 163-142
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 205/60 R16 96 W XL
    Tyre dimensions rear 205/60 R16 96 W XL
    Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
    Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (HP) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (HP) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,570
    Max. permissible weight in kg 2,050
    Permitted load in kg 555
    Permitted axle load front/rear in kg 965/1,150
    Luggage capacity min. (seats up or roof down) in l 480
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,600
    Trailer load 12% (braked) in kg 1,600

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
    Engine torque (Nm) at 1/min 300/1,350-4,000
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 235
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 7.1

    Fuel consumption

    Combined in l/100 km 7.2-6.3
    CO2 combined emissions in g/km 163-142
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 205/60 R16 96 W XL
    Tyre dimensions rear 205/60 R16 96 W XL
    Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
    Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (HP) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (HP) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,635
    Max. permissible weight in kg 2,130
    Permitted load in kg 570
    Permitted axle load front/rear in kg 1,050/1,185
    Luggage capacity min. (seats up or roof down) in l 480
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
    Engine torque (Nm) at 1/min 300/1,350-4,000
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 230
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 7.6

    Fuel consumption

    Combined in l/100 km 7.7-6.7
    CO2 combined emissions in g/km 174-152
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (HP) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (HP) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,580
    Max. permissible weight in kg 2,060
    Permitted load in kg 555
    Permitted axle load front/rear in kg 985/1,160
    Luggage capacity min. (seats up or roof down) in l 480
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,600
    Trailer load 12% (braked) in kg 1,600

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 190 (258)/5,000-6,500
    Engine torque (Nm) at 1/min 400/1,550-4,400
    Compression ratio : 1 10.2

    Performance

    Top speed in km/h 250
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 5.9

    Fuel consumption

    Combined in l/100 km 7.3-6.4
    CO2 combined emissions in g/km 167-147
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (HP) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (HP) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,660
    Max. permissible weight in kg 2,155
    Permitted load in kg 570
    Permitted axle load front/rear in kg 1,055/1,195
    Luggage capacity min. (seats up or roof down) in l 480
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 190 (258)/5,000-6,500
    Engine torque (Nm) at 1/min 400/1,550-4,400
    Compression ratio : 1 10.2

    Performance

    Top speed in km/h 250
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 5.6

    Fuel consumption

    Combined in l/100 km 7.6-6.7
    CO2 combined emissions in g/km 173-154
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (HP) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (HP) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,810
    Max. permissible weight in kg 2,245
    Permitted load in kg 510
    Permitted axle load front/rear in kg 1,115/1,230
    Luggage capacity min. (seats up or roof down) in l 480
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 6/4
    Capacity in ccm 2,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 275 (374)/5,500-6,500
    Engine torque (Nm) at 1/min 500/1,900-5,000
    Compression ratio : 1 10.2

    Performance

    Top speed in km/h 250
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 4.4

    Fuel consumption

    Combined in l/100 km 8.2-7.5
    CO2 combined emissions in g/km 188-172
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/45 R18 95 Y XL
    Tyre dimensions rear 255/40 R18 99 Y XL
    Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
    Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (HP) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (HP) -
    Combined torque Nm -
    BMW wheels and tyres EU tyre label close-up

    BMW WHEELS & TYRES.

    We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

    FUEL CONSUMPTION AND CO2 EMISSIONS.

    BMW 330i Sedan:
    Fuel consumption in l/100 km (combined): 7.3–6.4
    CO2 emissions in g/km (combined): 166–147



    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

    Read more
    ​

    Fuel consumption and CO2 emissions.

    • BMW 330i Sedan:
      Fuel consumption in l/100 km (combined): 7.3-6.4
      CO2 emissions in g/km (combined): 167-147

      Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
